WR-Series WR212

Overview

Wavestore WR212 servers deliver an enterprise recording, management and control solution for large size projects that demand mission-critical reliability. Up to 254 network cameras can be connected to the video servers, which are supplied with pre-installed Wavestore’s Video Management Software (VMS). Throughput of 1200Mbits/sec is provided, with 4 network interfaces to segregate incoming and outgoing network traffic. Ports can be bonded to provide fault-tolerance and maintain high-performance at all times.

Housed in a rack mountable 2U case, WR212 Video Servers come complete with dual power supply as standard and can accommodate up to 8 x 3.5” hot swappable hard drives to provide up to 144TB of storage. This can deliver 31 days continuous real-time recording from 254 Full HD cameras with RAID5 redundancy.

At a glance

Form factor: 2U rackmount

Server channels: Typically 254

Max. HDDs: 8 x hot swap

Max. storage: 144TB

Max. IP throughput: 1200Mbits/sec

RAID: MegaRAID (RAID5/6, N+1/2)

Failover ready: Yes

Operating System (OS): Linux with VMS embedded

Wavestore VMS: Pre-installed, ready to licence any level

Quick Camera Group setup: Yes

On-board WaveView client operation: For set-up only

Remote WaveView & WaveView Mobile client operation: Yes

Dual PSU: Yes

Standard warranty: Five-years on-site, next business day

Other warranty options: Four-hour response

Key features

Pre-installed with Wavestore’s highly secure VMS embedded into its Linux Operating System (OS)

Compatible with all Wavestore VMS levels
RAID5/6, N+1/2
Up to 4096bit encryption with comprehensive cyber-security package provided as standard
Fully ONVIF conformant and truly open-platform
Compatible with the world’s leading camera brands and video formats, including H.265, H.264, MJPEG, MPEG-4, MxPEG and JPEG2000

Downloads

Lined paper icon
Wavestore WR-Series WR212 Datasheet
DOWNLOAD
